Guide to use USBASP Programmar to burn Hex File to AVR Microcontroller.

Introduction : Robo India USBASP Programmer.

C#/vb.net excel,word,pdf component. AT89C51 The Chip we use is AT89C51. AT89C51 is an 8-bit microcontroller which belongs to Atmel's 8051 family. We use 4KB of Flash present in AT89C51 to place our program hex file. This is erasable read only memory (PEROM). It also has 128bytes of RAM. AT89C51 is a 40 pin device and it has four ports designated as P1, P2, P3 and P0. Page 4 AT89C51 controller in the application. The load address dem and programmer monitor the phone line for incoming field contains the address at which the data is to be writ- calls. Page 5 Microcontroller It is important to note that invalid packets are NEVER pro- Switch settings: grammed into the application controller.

USBasp is a USB in-circuit programmer for Atmel AVR controllers. It simply consists of an ATMega8 and a couple of passive components. The programmer uses a firmware-only USB driver, no special USB controller is needed, and that makes it low cost USB programmer.

Important features are:

Works under multiple platforms. Linux, Mac OS X and Windows are tested.
Jumper for 5v supply.
Header Pin to provide easy interface for various ISP header pin.
SCK option to support targets with low clock speed (< 1.5MHz).

Installation:

Install USBASP as simple usb device.

Download : Drivers 32&64 bit

Here is a wonderful guide on how to install USBASP on windows 8. click here

Atmel At89c51 Programmer

Uploading hex file to AVR Microcontroller:

To transfer the Hex file to controller we require a software to access USBASP. There are lots of softwares available on internet.Software which we find easy to use with all features is Prog ISP.

Download:

Note: no need to install install Prog ISP just unzip the file and click on progisp.exe executable file to launch the software.

Hardware Set up:

Connect USBASP to your AVR microcontroller board using 6 pin connectors, where 5v is optional, if your board is already powered by some external 5v supply than remove the jumper(vcc on/off).

Troubleshooting:

Prog ISP will show error in case:

Supply is not provided to target controller.
wrong connection to Target microcontroller.
USBASP not detected.

Note: keep the Jumper (J1) always connected.

Getting Started with Prog ISP:

Select Chip: Select the microcontroller for uploading Hex file.
Load Flash: This tab is used to select the Hex file,Click this tab to open browse window and select the Hex file.
Task Window: Select the operation which you want to complete. basic operation required to burn hex file are shown above.
Auto: Click on this tab to start burning the hex file along with all the operation checked in task box.
Fuse: This tab is used to open Fuse window as shown below,where you can read or write low and high value of fuses.

Steps to Upload Hex File:

Install USBASP Programmer.
Connect Hardware.
Select microcontroller in ProgISP.
Load Hex File.
Click Auto tab to transfer the code.
